ĐẦU GHI CAMERA GIÁM SÁT HÀNH TRÌNH 2 KÊNH D16FHD – HÀN QUỐC
Mã Hàng: D16FHDĐặt Hàng
– Full-HD 1080P (VGA & HD)
– Bộ nhớ SD (Lên đến 256GB)
– GPS tùy chọn
– Tích hợp G-Sensor
– Giám sát pin yếu (Chức năng ngắt)
– WIFI (Ứng dụng)
– PC Viewer
– Ổ cắm thẻ nhớ Micro SD / Tối đa 256GB / Tùy chọn: SSD 500GB
Xuất xứ: Hàn Quốc
Cho phép đặt hàng trước
-
-
o Part name Spec 1 Main CPU Davinci Digital Media Processor Up to 1000-Mhz ARM Cortex –A8 RISC Processor 256KB of On-Chip Memory Controller 2 MICOM 16Bit RISC Microcontroller 3 Memory 128MB NAND Flash Memory 4 RAM 256*2(512MB) DDR III RAM 5 Composite NTSC Composite Video Output (2.5mm Jack) 6 Video Input 2ch Full-HD Rear Camera (with AHD) 7 Wi-Fi Interface USB 2.0 Interface 8 SD CARD Micro SD Card Socket / Upto 128GB 9 G-Sensor Tri-Axis Digital Accelerometer 10 Temperature Operation Temperature: 0℃ ~ 60℃ Store Temperature: – 20℃ ~ 80℃
11 GPS UART Interface GPS 12 RTC Internal Real Time Clock (With Back up Battery) 13 MIC Microphone Port (3.5mm Jack) 14 Speaker Internal Mylar Speaker 15 Status LED Red (Power On/OFF Indicator) Green LED 2ea (Status Indicator ) 16 KEY Recode Switch Power On/Off Key 17 GPIO External GPIO Signal Input Port 18 Debug Ethernet & UART Debug 19 Buzzer Beep Sound Buzzer 20 Power Input :DC 10V ~30V Power Consumption : 5W(2CH@30fps)=>LCD off except GPS, network
-
